Right back in January we brought you news that JVC had worked out some magic for making super-slim LCD TVs, and now they're official products. The 42-inch LT-421L89 and the 46-inch LT-46SL89 measure up at just 1.5-inches deep (2.9-inches at the center) and let JVC say they're the "world's thinnest tuner-equipped LCD TVs." The tuner-equipped part distinguishes them from skinnier Aquos TVs, which dump the electronics to a separate box. They're full HD, and will be available July for $1,899.99 for the 42-inch and $2,399.99 for the 46-inch. Press release below.
JVC TO OFFER WORLD'S THINNEST TUNER-EQUIPPED LCD TV WITH SLEEK, THIN-BEZEL DESIGN AND REDUCED POWER CONSUMPTION
Technology to be offered in two screen sizes
WAYNE, NJ, June 17, 2008 -Establishing a new benchmark in flat panel TV design, JVC in July will market the world's thinnest LCD TVs with built-in tuners*. The new line of super-slim Full HD TVs also weigh less and consume less power than conventional LCD TVs.
JVC's new slim LCD TVs, part of the company's Procision series, feature a cabinet that across most of its width measures a mere 1.5 inches (39mm) deep, with a maximum depth of just 2.9-inches (74mm) at the panel's center. The design ensures that from nearly any angle, the sets present a super-slim appearance. Complementing the slim design is a thinner bezel, further minimizing the presence of the cabinet.
The new super-slim design will be available in two screen sizes in the U.S., the 42-inch LT-42SL89 and the 46-inch LT-46SL89. Both offer 1920 x 1080p resolution.
The slim design was made possible through the use of a new JVC-developed slim panel backlight unit and power supply substrate, or chassis. The new slim LCD panel backlight unit is 40 percent smaller in depth and bezel width compared to a conventional LCD backlight, measuring just 0.79 inches (20mm) deep and 0.51 inches (13mm) wide. In addition, the unit weighs only 26.4 lbs (12kg) and consumes a mere 145W (see diagram 1).
*with built-in tuners as of January 6, 2008, according to a JVC survey
Efforts to reduce the depth of an LCD panel backlight result in uneven hot spots appearing on the LCD screen surfaces because CCFL light sources are brought closer to the liquid crystal panel (see diagram 2). To overcome this problem, either light-diffusing plates are applied or more CCFL tubes are used. But the former approach can result in lower brightness, while the latter approach can be costly and increases power consumption.
JVC's display engineering team succeeded in developing a new, slimmer backlight unit by optimizing the light-diffusing plates and light-reflection sheets, as well as improving its overall composition. This provided uniform light-diffusion at all the corners and edges without the addition of more CCFL tubes, while maintaining adequate luminance to ensure that the screen always remains bright (see diagrams 3 and 4).
JVC also developed a slimmer yet efficient power-supply substrate and employed a direct-mount configuration for it on the LCD panel backlight unit with a fan-less heat dissipation system to further reduce power consumption.
Both models will be VESA compliant for easy wall mounting, but JVC will also offer its own mounting solution - a wall mount designed to position the slim TV closer to the wall than does a standard mount.
Both sets include a full complement of connections, including three HDMI inputs, two component inputs, one S-Video in and a PC input. Other features include front touch sensor controls, a headphone jack, USB picture viewer and an illuminated universal remote control.
The new JVC super-slim LT-42SL89 and LT-46SL89 will be available in July with approximate retail prices of $1,899.99 and $2,399.99, respectively.
