New Study Details Toxic Particles Spewed by 3D Printers

We may earn a commission from links on this page.
Image for article titled New Study Details Toxic Particles Spewed by 3D Printers
Image: Elena Scotti Photos: (Shutterstock)

Researchers have that found that 3D printers spew tiny particles into the air as they operate, though the quantity and nature of these potentially toxic aerosols are poorly understood. A new study identifies a startling variety of these emissions, and the conditions under which they’re produced.

Previous studies have already shown that small particle emissions are being released by desktop 3D printers, but scientists hadn’t performed controlled experiments to accurately detect and characterize the particles and chemicals associated with the printing. A newly published, two-year investigation to assess the impacts of desktop 3D printers on indoor air quality, conducted by scientists at UL Chemical Safety and Georgia Institute of Technology, now overcomes these shortcomings. The results, published in two separate studies in Aerosol Science and Technology (here and here), were not encouraging; in tests, the researchers were able to identify hundreds of different compounds, some of which are known health hazards.


These findings come at a time when these low-cost machines are increasingly appearing in commercial, medical, and educational settings. Marilyn Black, vice president and senior technical advisor at UL and a co-author of both studies, says her team’s findings should serve as a wakeup call, and they’re asking health researchers, scientists, and other institutions to investigate further.

“Because of the potential health concern indicated in the early studies, we saw the opportunity to conduct a scientifically controlled laboratory research study to measure and characterize these emissions and understand why they occur and to evaluate their toxicity,” Black told Gizmodo. “Our study was able to develop a robust environmental chamber technology that allows for consistent and accurate measurements, the identification of the particles and chemicals, and determination of human exposure levels.”


Standard desktop 3D printers produce detectable amounts of ultrafine particles, or UFPs, while performing print jobs. UFPs are nanoscale particles that are invisible to the human eye, but could lead to serious health issues, particularly if they’re inhaled and delivered to the body’s pulmonary system.

“Ultrafine particles are very fine particles that are less than 0.1 micron (100 nanometers) in diameter,” said Black. “More than 90 percent of the particles we found emitting from 3D printers were in the nanoparticle range. These small particles, when inhaled, can reach the deepest part of the lungs, where they can enter tissues and cells, and can lead to cardiovascular and pulmonary effects in humans.”

When a printing process is initiated, a burst of new particles is created, which then becomes airborne. It’s this initial batch that tends to contain the smallest sizes and the maximum number of UFP concentrations during the entire print job, according to the new research.

In tests, the researchers primarily looked at filament fabrication printers that use thermoplastic or nylon-containing feedstocks (Black said additional feedstocks and other print technologies will be studied in future work). Specifically, the researchers looked at FDM 3D printers (fused deposition modeling), which are known to produce some of the highest levels of UFPs. As described by 3D Hubs, FDM printers build objects by selectively depositing melted material layer-by-layer along a predetermined path. FDM printers are the most widely used 3D printing technology around the world, and include the popular MakerBot line of 3D printers.


Black’s team conducted a small number of toxicity tests on these printers using several methods, including chemical tests and in vitro cellular assays (the use of live cells). Two common filament types were studied, called ABS (Acrylonitrile Butadiene Styrene) and PLA (Polylactic Acid), and all tests indicated at least some level of toxic response (though the toxic response varied by filament type).

The sheer variety of the toxic substances produced by these printers was alarming. No less than 200 different volatile organic compounds (VOCs) were detected in the invisible puffs emanating from the printers as they churned away—including many known and suspected irritants and carcinogens. Common VOCs detected included formaldehyde (an organic compound and a known carcinogen), styrene (a flammable chemical and irritant), and caprolactam (a particularly nasty manufacturing compound that can cause irritation and burning of the eyes and throat, headaches, confusion, and gastrointestinal problems).


The researchers also documented the different factors involved in the production of UFPs. Factors that affected the types of UFPs produced include the temperature of the nozzle, the type of filament used, the filament and printer brand, and filament color. Factors that affected emission levels included extrusion temperature, filament material, and the filament brand.

“Our research provides technical information on the mechanism for particle formation and shows the operational factors make a difference,” Black told Gizmodo. “This information can assist manufacturers in adapting new technologies and controls to minimize or reduce the emissions.”


This study was not a detailed look into the long-term health effects of 3D printers. Accordingly, the researchers are now asking scientists to perform a complete risk assessment to determine dangerous levels of toxic emissions, while asking manufacturers to do what’s necessary to minimize emissions. They also want the manufacturers to bring this issue to the attention of their customers such that they can take the necessary precautions.

Black had this advice to users of desktop 3D printers.

“Use only in well-ventilated spaces with outdoor air flow and stand away from the printers during operation,” she said. “Choose and select printers and feedstocks that have been proven to be low emitters.”


Desktop 3D printers, though wonderful, are introducing a surprising variety of problems. From security concerns and the manufacturing of illicit devices, and now their potential health effects, these machines are not merely the fun toys they’re often portrayed to be.


[Aerosol Science and Technology, Aerosol Science and Technology]
