Pretty Scientific is a new Gizmodo series where we explore how the best images in science were created and why.
Three pillars of gas and dust sit among stars like towers of billowing smoke. It would take several years for light to cross from the top to the bottom of these dusty columns. This striking image from the Hubble Space Telescope remains, to this day, one of the most well-known astronomical images ever taken.
But if you were to peer at the Pillars of Creation, part of the Eagle Nebula, through your own telescope, you wouldn’t see the same thing. The images you typically see of outer space are colorized and processed in order to bring out the detail and highlight the most relevant parts for scientific study. The popularity of the Pillars of Creation may have forever changed how astronomers present images of space to the public.
“Because of the public desire to see pictures like this, an awful lot of people started rendering their press releases using these kinds of images,” Paul Scowen, Arizona State University astronomer and one of the image’s creators, told Gizmodo. “It had an impact on the way the data of Hubble was seen and digested by the public as a general result.”
The larger Eagle Nebula (also called M16) that contains the Pillars consists of thousands of stars and the dust clouds that created them. The Pillars contains dark globs of gas that could one day collapse and begin emitting radiation themselves—new stars. The Pillars make up only a small part of the 70-by-55 light-year structure; the largest pillar is around four light-years high.
A team of astronomers imaged the nebula to create the Pillars of Creation image back in 1995 using the Hubble Space Telescope. Hubble orbits Earth and collects light with a large, curved mirror, then reflects it onto a smaller secondary mirror, sending the light back through a hole in the curved mirror into the instruments. There are several instruments capable of analyzing all of that light in different ways.
The instrument that captured the Pillars, the WFPC2, actually consists of four cameras whose images astronomers must combine. Each camera takes a quarter of the full picture, but the Planetary Camera (PC) takes a magnified view which needs to be scaled down, said Scowen. That’s why the top right square is so much smaller, creating what he affectionately calls the “stealth bomber effect.” Aligning all the data was perhaps the most challenging part, he said.
This image isn’t as magnified as you might think—the Pillars would be more than a tenth the size of the full moon in the night sky if they were bright enough to be seen with the naked eye. Instead, what’s great about Hubble is the quantity of light particles it can collect from distant, faint things. It builds images from each bit like you might build a comic strip out of lots of tiny dots.
But unlike a comic strip, you can’t look at every color, or wavelength, of the Hubble light at the same time. The researchers block out much of the light using a filter, and only look at plates covering certain scientifically interesting light wavelengths at a time. In the case of the famous Pillars of Creation image, they were interested in the light emitted by certain excited oxygen, hydrogen, and sulfur atoms.
Normally, this would result in black-and-white images, depicting only the light that arrived at 502 nanometers for the oxygen, 657 nanometers for the hydrogen, and 673 nanometers for the sulfur. This translates to green light and two indistinguishable shades of red—probably not the best three colors for an image to present to the public. Instead, the researchers combined the three images, depicting the oxygen emission in blue, the hydrogen in green, and the sulfur in red.
Some might feel duped, but “you’d never get an image like this with a backyard telescope because of the Earth’s atmosphere,” Kate Whitaker, astronomer from the University of Connecticut told Gizmodo, though the Pillars are visible on a dark night with very large telescopes. “You wouldn’t see the details you see with the Hubble images,” she said. And the researchers never claimed this is what Pillars really look like, said Scowen. Instead it’s data that Hubble really saw, presented in a more scientifically meaningful way.
Scientists have continued observing the Eagle Nebula, and they re-imaged it with updated instrumentation for the Hubble Space Telescope’s 25th anniversary. They have even tried to view it in three dimensions. The dust is nearly opaque when observed with visible light, but viewing only the infrared light has allowed scientists to peer inside the pillars themselves. This also reveals the large number of stars formed by the nebula. Others have imaged the x-rays coming from the pillars using NASA’s Chandra X-ray Observatory, showing the light of new stars forming at the tip of the biggest pillar.
Some worried that new observations implied that the Pillars were no more—other images taken in the infrared seem to show a supernova’s explosion approaching them. Perhaps humans saw this supernova in the sky a millennium ago, but if the Pillars have been wiped out, the light showing their destruction hasn’t reached Earth yet. More recent data seems to have refuted the idea that a supernova has already destroyed pillars.
Regardless, the image will remain a permanent fixture in astronomy lore. Said Scowen: “It continues to be held up as one of the most popular Hubble pictures ever taken.”
