This Robot Is the Rembrandt of Painting With Light

Illustration for article titled This Robot Is the Rembrandt of Painting With Light

The more traditional technique of light painting involves creating freehand designs using a point of light in front of a camera taking a long exposure photo. The results are occasionally recognizable—but most often random—and that's part of their appeal. Jeff Crossman and Kevyn McPhail take a different approach, though, using a robot arm to create perfectly pixelated light painting images.


It would be easy to call their use of an ABB IRB 6640 industrial robot as their photography assistant cheating, but the results are just too unique to dismiss. Besides, Flickr is already chock full of random glowing streaks.

The source images for the light paintings are captured using an Xbox's Kinect camera, and the data is then processed with 3D software and other tools to generate a point cloud often composed of as many as 5,000 dots. The end of the robot arm is equipped with a flashing RGB LED that can generate any color, and slowly, over the course of about 25 minutes, it recreates that 3D point cloud as a light painting.

It's a tedious process, but the precision of the robot arm means its creators could even move on to creating light painting animations. Which is something that would be all but impossible, relying on a human's imprecise hand movements. [Jeff Crossman & Kevyn McPhail via Engadget]



Automation IG

Industrial robots have incredible capabilities. We (shameless plug - Automation IG) made some light painting scripts as a proof of concept for one of our bids. Image below took less than 45 seconds with an ABB IRB1600ID, it's hitting about 4000 points to within 0.02mm in space and was only going 50% speed.

Here's the 1600id with some of it's big brothers in the background that haul 200lb+ spot guns.
